Lò nung điều khiển bằng PLC SM-GHP-9050 SM-GHP-9050N SM-GHP-9080 SM-GHP-9080N SM-GHP-9160 SM-GHP-9160N SM-GHP-9270 SM-GHP-9270N

◆Humanized design

● Brushed finished stainless steel liner, semicircle design(Four corners), easy cleaning, rack adjustable.

● Water-jacket heating mode. Temperature is even in the working chamber. if power failure, the chamber can keep constant temperature longer.

● Observation window in the liner for convenient uses, incubator will be shut down automatically when the door open.

● Micro-computer controller, accuracy temperature control; With temperature, water level and door-open alarm function. Can protect the testing samples safely.

◆Automatic control of circulating fan speed, avoiding the volatilization of samples effectively.

● Multi-segments Programmable LCD controller(Model ends with ’N’ have this function)

● Multi-segments Programmable LCD controller, data focus, Menu operation interface, simplify the complicated experimental process, truly put automatic control into effect.

● Multi-segments temperature, circulation velocity, timing and heating rate can be set and programmed together. Gradient Acceleration Control, automatic start-up and shut down function.

◆Safety function

● Independent temperature warning system; sound-light alarm(optional choice).

● over & below temperature and water shortage also trigger the alarm.

● Long time door-open alarm;

◆UV sterilization system.(Optional choise)

● The UV sterilization system disinfect virus and prevent the incubator from being pollution.

---

Model	SM-GHP-9050	SM-GHP-9080	SM-GHP-9160	SM-GHP-9270
	SM-GHP-9050N	SM-GHP-9080N	SM-GHP-9160N	SM-GHP-9270N
Power supply	AC220V 50HZ
Heating method	water-jacket
Temperature control range	RT+5～65℃
Temperature fluctuation	0.1℃/±0.3℃
Temperature uniformity	±0.5℃（Test   Temperature is 37℃）
Operating ambient temperature	+5～35℃
Input Power	450W	650W	850W	1350W
Volume	50L	80L	160L	270L
Liner dimension	350×350×410	400×400×500	500×500×650	600×600×750
(W×D×H mm)
Outside dimension	500×500×700	550×550×800	650×640×950	750×740×1050
(W×D×H mm)
Loading   Bracket(Standard)	2 pcs
Time setting range	0～9999min

1. Multi-segments Programmable LCD controller;

2. Embedded printer;

3. Independent temperature limited controller;

4. RS485 connector and communication software;

5. UV sterilization system;

6. Automatic water adding system
